Globalmediapro GPS-601 Wrist GPS Receiver
DISCONTINUED
SiRF Star III high performance GPS chipset.
GPS-601 provides a fully-sealed, waterproof, large LCD wrist-watch device, as well as a GPS navigation function that locates and tracks points from start to stop. It is adopted for people who exercise for broad kinds of outdoor sports, such as Jogging, Running, Biking, Snow Skiing, etc. It also can be used as GPS receiver by USB interface.
Features
1. Built-in SiRF Star III high performance GPS chipset. Excellent sensitivity for fixing the position even at a weak signal status.
2. With an omni-directional GPS antenna, it can receive the signal from all directions.
3. With built in rechargeable lithium-ion battery.
4. Large LCD for easy read.
5. Waterproof design to avoid damaging with carelessness.
6. Recording all history of self training by defined day.
7. Coach mode : Define a target performance to be achieved.
8. Workout project : Define the project which user would like to achieve.
9. Alert : While user is slower / faster the define performance.
10. Navigation :
map the location;
mark the trace point;
find the marked point;
backtrack mode;
ahead / north direction.
Software Feature
Professional self-training and compute software, supporting the operating system such as Windows 98 /2000 /XP.
Specifications
Electrical and Mechanical Parameters General
Item: GH-601
Number of Waypoints: 100
Display Size: 24.9 x 39.88 (H x W in mm.)
Display type: Black & White LCD
Pixels (H x W): 80 x 120
Unit Weight: 72.87g
Waterproof Standard: IPX7
Unit Size: 46 x 82.5 x 18.5 (H x W x D in mm.)
Backlit Display:Single level
Operating temperature: -20 oC to 60 oC
Humidity: 5% to 95% Non-condensing
Voltage: 3.7V for a rechargeable battery, 5V for charging input
Charging connector: DC 5V
Battery: Rechargeable 1600mAh Li-ion battery
Battery life: 16 hours (GPS turn-on; Compass and Altimeter turn-off)70 hours (GPS, Compass and Altimeter turn-off)
Connect to PC Interface: Mini-USB port
GPS Parameters General
GPS Chipset: SiRF Star III
Frequency: L1, 1575.42 MHz
C/A code: 1.023 MHz chip rate
Channels: 20 channel all-in-view tracking
Antenna Type: Built-in patch antenna
Position: 10 meters, 2D RMS 5 meters, 2D RMS, WAAS enabled
Velocity: 0.1 m/s
Time:1 us synchronized to GPS time
Default datum: WGS-84
Reacquisition: 0.1 sec., average
Hot start: 1 sec., average
Warm start: 38 sec., average
Cold start: 42 sec., average
Altitude: 18,000 meters (60,000 feet) max.
Velocity: 515 meters/ second (1000 knots) max.
Acceleration: Less than 4g
Jerk: 20 m/sec3
Physical Material List
Top Cover: PC with TPR
Bottom Cover: PC
Wrist Strap: Weaved cloth
Waterproof Stopper: TPEE
LCD Faceplate: Acrylic
