Features
3 programs for saving of different settings
2-, 4- and 16-split (multi-picture print)
2-, 4- and 16-split (photo print)
counter for remaining number of prints
reversed print direction
mirrored print
comments lines
paper hold function
button control
gamma curves for ultrasound, endoscopy and microscopy
Specifications
Print Method: Dye Sublimation
Resolution : Printhead 325 dpi (12.8dots/mm), max. resolution 1280 x 1200 dots
Color Depth : 24 Bit, each 256 color gradiations for yellow, magenta and cyan, 16.7 million colors
Print Speed:
S-Format : 12 seconds (Fast mode), 19 seconds (Normal mode)
L-Format : 22 seconds (Fast mode), 36 seconds (Normal mode)
Paper Size:
S-Format : 110 x 105 mm
L-Format : 160 x 110 mm
Print Area:
S-Format : 100 x 75 mm, 1280 x 600 dots
L-Format : 125 x 94 mm, 1280 x 1200 dots
Memory : 8 MB
Greyscale : 256 levels
Interface : USB 2.0
Print Capacity : Up to 254 set at (1280 x 960) page size
Input Signal: Standart composite video (NTSC and PAL) (BNC)
Dual Power Supply:
AC 100-120V, 50/60 Hz
AC 220-240V, 50/60 Hz
Power Consumption: 1.5 to 0.8 amps
Regulatory Approvals : UL2601-1; CAN.CSA C22.2 No.601-1(C-UL), FCC-Class A, TUV GS, TUV GM; CE (LVD, MDD) CE Mark (EMC; 89/336/EEC)
In the Box
Power cable
Ink sheet cassette
4 spacers
Wire remote control
Operatiion manual
Attachments for thermal paper
