Features
HDV and DV capture
Additional 2 channels balanced audio
Removable HDD
No file size limitation
Multiple power options
RGB output for quick control and thumbnail view
Network ability (control multiple units and file transfer)
Utility software for previewing. file management and basic editing
Specifications
Video Format : HDV (.m2t), DV (.dv)
Audio Format : 16-bit/48KHz (Supports broadcast wav : .bwf)
Audio Control : Gain, Phantom Power Supply (+48V)
Recording Media : Removable type 2.5inch 120GB HDD
Input Jacks:
Digital Video Input (IEEE1394, 6pin type)
Analog Audio Input x 2 (XLR 3pin type)
Input Impedance : 4K ohms
Phones Output (Stereo mini type)
Output Impedance : 16 ohms
Output Level : 45mW
Monitor Output (Analog RGB, D-Sub 15pin type)
USB host (USB A)
USB function (USB mini B)
Network (Ethernet 100Base-Tx, RJ45 type)
DC Input (XLR 4pin type)
Battery AA type x 8 (NiMH or Alkaline)
Max 2 hours operation
USB cable (Y type with power supply)
AC adaptor (9V / 2A, Roland PSB-1U) with XLR 4pins conversion cable
CD-ROM (F-1 utility)
Owner's Manual
Dimensions W:111 x H:61 x D:179 mm (W: 4-3/8 x H: 2-3/8 (H) x D: 7-1/8)
Weight 870g or 1.92lbs (Including HDD, excluding batteries)
In the Box
USB cable (Y type with power supply)
Power cord
AC adaptor (9V / 2A, Roland PSB-1U) with XLR 4pins - conversion cable
120GB removable HDD (F1-HD120)
Battery case
Operation manual
