Specifications
Power supply : DC7.2V(using with battery), DC7.3V(with AC Adaptor)
Power Consumption : 9.8W (when recording)
Operation temperature : 0oC to 40oC
[CAMERA]
Pick-up Device: 3CCD (1/3-inch interline transfer type, and progressive modes supported)
Lens: LEICA DICOMAR lens with optical image stabilizer, motorized/manual mode switching,
F1.6-3.0 f=3.9mm to 51mm/35mm equivalent: 28mm to 368mm)
Optical Color Separation: Prism system
ND Filter: 1/4, 1/16, 1/64 (72mm)
Gain Selection: 60i/60p mode: 0/+3/+6/+9/+12/+18 dB, (0dB fixed in slow shutter mode)
30p/24p mode: 0/+3/+6/+9/+12 dB, (0dB fixed in slow shutter mode)
Shutter Speed: 60i/60p mode: 1/60 (OFF), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000 sec.
(Preset) 30p mode: 1/30, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 sec.
24p mode: 1/24, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 sec
Shutter Speed: 60i/60p mode: 1/60.0 sec. to 1/249.8 sec.
(Synchro Scan) 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec.
Slow Shutter Speed: 60i/60p mode: 1/15, 1/30 sec. 30p mode: 1/15 sec.
Minimum Luminance: 3lx, (F1.6, Gain: +12dB, Shutter: 1/24sec.)
Digital Zoom: 2x/5x/10x (only in 1080/60i or 720/60p video format)
Filter Diameter: 72mm
with Lens hood
[Recording]
Recording Format: AVCHD
Compression Method: MPEG-4 AVC/H.264
Recording Media*: SD Memory Card : 512MB, 1GB, 2GB (FAT12, FAT16)
SDHC Memory Card : 4GB, 6GB, 8GB, 12GB, 16GB, 32GB (FAT32)
Recording Video Format: PH mode: 1080/60i, 1080/30p (over 60i), 1080/24p (native), 720/60p, 720/30p(over 60p) and 720/24p (native)
HA, HG and HE mode: 1080/60i only
Transmission Rate: PH mode: approx. 21 Mbps (VBR, Max 24Mbps)
HA mode: approx. 17 Mbps (VBR),
HG mode: approx. 13 Mbps (VBR)
HE mode: approx. 6 Mbps (VBR)
[Video System]
Video Signals: 1080/60i, 720/60p
HDMI Output: HDMI x 1, 1080/60i, 720/60p, 480/60p (Not compatible with VIErA Link)
Component Output: Mini-D x 1, Y: 1.0 Vp-p, 75 Ohm, PB/PR: 0.7 Vp-p, 75 Ohm
Composite Output: Pin jack x 1, 1.0 Vp-p, 75 Ohm
[Audio IN/OUT]
XLR Input: XLR (3 pins) x 2 (INPUT1, INPUT2), High impedance
LINE: 0 dBu, MIC: -50 dBu/-60 dBu (selectable in menu)
Internal Microphone: Stereo microphone
Line Output: Pin jack x 2 (CH1, CH2), Output: 316 mV, 600 Ohm
HDMI Output: 2 ch (Linear PCM), 5.1 ch (AC3)
Headphone: Stereo mini jack (3.5 mm diameter) x 1
Built-in Speaker: 20 mm (round) x 1
LCD Monitor: 3.5 inches, LCD color monitor, 210,000 pixels
Viewfinder: 0.44 inches, LCD color viewfinder, 235,000 pixels
USB: Type mini B connector (compliant with USB ver. 2.0)
Camera Remote: Super Mini jack (2.5mm diameter) x 1, for zoom and rec start/stop operations
Mini jack (3.5mm diameter) x 1, for focus and iris controls
TC PRESET IN/OUT : IN: 1.0 to 4.0 Vp-p, 10 k Ohm
(also used for VIDEO OUT) OUT: 2.0+/-0.5 Vp-p, low impedance
Power Consumption : 9.8W (when recording)
Operation temperature : 0oC to 40oC
[CAMERA]
Pick-up Device: 3CCD (1/3-inch interline transfer type, and progressive modes supported)
Lens: LEICA DICOMAR lens with optical image stabilizer, motorized/manual mode switching,
F1.6-3.0 f=3.9mm to 51mm/35mm equivalent: 28mm to 368mm)
Optical Color Separation: Prism system
ND Filter: 1/4, 1/16, 1/64 (72mm)
Gain Selection: 60i/60p mode: 0/+3/+6/+9/+12/+18 dB, (0dB fixed in slow shutter mode)
30p/24p mode: 0/+3/+6/+9/+12 dB, (0dB fixed in slow shutter mode)
Shutter Speed: 60i/60p mode: 1/60 (OFF), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000 sec.
(Preset) 30p mode: 1/30, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 sec.
24p mode: 1/24, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 sec
Shutter Speed: 60i/60p mode: 1/60.0 sec. to 1/249.8 sec.
(Synchro Scan) 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec.
Slow Shutter Speed: 60i/60p mode: 1/15, 1/30 sec. 30p mode: 1/15 sec.
Minimum Luminance: 3lx, (F1.6, Gain: +12dB, Shutter: 1/24sec.)
Digital Zoom: 2x/5x/10x (only in 1080/60i or 720/60p video format)
Filter Diameter: 72mm
with Lens hood
[Recording]
Recording Format: AVCHD
Compression Method: MPEG-4 AVC/H.264
Recording Media*: SD Memory Card : 512MB, 1GB, 2GB (FAT12, FAT16)
SDHC Memory Card : 4GB, 6GB, 8GB, 12GB, 16GB, 32GB (FAT32)
Recording Video Format: PH mode: 1080/60i, 1080/30p (over 60i), 1080/24p (native), 720/60p, 720/30p(over 60p) and 720/24p (native)
HA, HG and HE mode: 1080/60i only
Transmission Rate: PH mode: approx. 21 Mbps (VBR, Max 24Mbps)
HA mode: approx. 17 Mbps (VBR),
HG mode: approx. 13 Mbps (VBR)
HE mode: approx. 6 Mbps (VBR)
[Video System]
Video Signals: 1080/60i, 720/60p
HDMI Output: HDMI x 1, 1080/60i, 720/60p, 480/60p (Not compatible with VIErA Link)
Component Output: Mini-D x 1, Y: 1.0 Vp-p, 75 Ohm, PB/PR: 0.7 Vp-p, 75 Ohm
Composite Output: Pin jack x 1, 1.0 Vp-p, 75 Ohm
[Audio IN/OUT]
XLR Input: XLR (3 pins) x 2 (INPUT1, INPUT2), High impedance
LINE: 0 dBu, MIC: -50 dBu/-60 dBu (selectable in menu)
Internal Microphone: Stereo microphone
Line Output: Pin jack x 2 (CH1, CH2), Output: 316 mV, 600 Ohm
HDMI Output: 2 ch (Linear PCM), 5.1 ch (AC3)
Headphone: Stereo mini jack (3.5 mm diameter) x 1
Built-in Speaker: 20 mm (round) x 1
LCD Monitor: 3.5 inches, LCD color monitor, 210,000 pixels
Viewfinder: 0.44 inches, LCD color viewfinder, 235,000 pixels
USB: Type mini B connector (compliant with USB ver. 2.0)
Camera Remote: Super Mini jack (2.5mm diameter) x 1, for zoom and rec start/stop operations
Mini jack (3.5mm diameter) x 1, for focus and iris controls
TC PRESET IN/OUT : IN: 1.0 to 4.0 Vp-p, 10 k Ohm
(also used for VIDEO OUT) OUT: 2.0+/-0.5 Vp-p, low impedance
